PAGE 12 — DCA125SSIU 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (12/22/08)
Generator Specifi cations Table 1.
Model DCA-125SSIU
Type
Revolving fi eld, self ventilated,
open protected type synchronous generator
Armature Connection Star with Neutral Zigzag
Phase 3 Single
Standby Output 110 kVA (88 kW) 63 kW
Prime Output 100 kVA (80 KW) 57 KW
Power Factor 0.8 1.0
Voltage 200 or 400V 100 or 200V
Frequency 50 Hz
Speed 1500 rpm
Aux. AC Power Single Phase, 50 Hz
Aux. Voltage/Output 4.8 Kw (2.4 kW x 2)
Engine Specifi cations Table 2.
Model ISUZU 4HK1X
Type
4 cycle, water-cooled, direct injection, turbo-charged
with charged air-cooled
No. of Cylinders 4 cylinders
Bore x Stroke 4.53 in. x 4.92 in. (115 mm x 125 mm)
Displacement 317 cu. in. (5,193 cc)
Starting Electric
Coolant Capacity 5.30 gal. (20.2 liters)
Lube Oil Capacity 5.99 gal. (22.7 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 63 gal. (240 liters)
Fuel Consumption 5.8 gal. (22.0 L)/hr at full loa
Battery 12V-128 Ah x 1
SPECIFICATIONS
