page 12 — DCa40sskU/kU4i 60 hz generaTor • operaTion anD parTs manUal — rev. #1 (03/11/13)
speCifiCatiOns
Table 1. generator specifications
model DCA-40SSKU/KU4i
Type
Revolving field, self ventilated,
open protected type synchronous generator
armature Connection star with neutral zigzag
phase 3 Single
standby output 31.2 KW (39.0 kVA) 22.5 KW
prime output 30.0 KW (37 kVA) 21 KW
3Ø voltage (l-l/l-n)
voltage selector switch at 3Ø 240/139
208Y/120, 220Y/127,
240Y/139
N/A
3Ø voltage (l-l/l-n)
voltage selector switch at 3Ø 480/277
416Y/240, 440Y/254,
480Y/277
N/A
1Ø voltage (l-l/l-n)
voltage selector switch at 1Ø 240/120
N/A 240/120
power Factor 0.8 1.0
Frequency 60 Hz
speed 1800 rpm
aux. aC power Single Phase, 60 Hz
aux. voltage/output 4.8 Kw (2.4 kW x 2)
Dry Weight 2,039 lbs. (925 kg)
Wet Weight 2,282 lbs. (1,035 kg)
Table 2. engine specifications
model Kubota V3300-E3BG EPA Interim Tier 4 Certified
Type 4-cycle, water cooled, swirl chamber
no. of Cylinders 4 cylinders
Bore x stroke 3.86 x 4.33 in. (98 x 110 mm)
Displacement 202. in 3 (3.3 liters)
rated output 41.2 HP at 1800 rpm
starting Electric
Coolant Capacity 2.91 gal. (11.0 liters)
lube oil Capacity 3.49 gal. (13.2 liters)
Fuel Type Ultra Low Sulfer No. 2 Diesel Fuel
Fuel Tank Capacity 26.4 gal. (100 liters)
Fuel Consumption
2.6 gal. (9.8 L)/hr at full load 1.9 gal. (7.3 L)/hr at 3/4 load
1.4 gal. (5.4 L)/hr at 1/2 load 1.0 gal. (3.8 L)/hr at 1/4 load
Battery 27 (CCA 0° 800A) x 1
