DCA-70USJ — OPERATION AND PARTS MANUAL — REV. #0 (09/16/04) — PAGE 77
1
ENCLOSURE #1 ASSY.
NO. PART NO. PART NAME QTY. REMARKS
28 0010120050 BOLT, HEX HEAD 4
28A 0030020000 HEX, NUT 4
28B 0040020000 SPRING WASHER 4
28C 0041220000 PLAIN WASHER 8
29 M2463100102 ROOF PANEL 1
29A M2493501304 ACOUSTIC SHEET 1
30 M2463200102 ROOF PANEL 1
30A M2493502203 ACOUSTIC SHEET 1
31 M3463200704 BACK PLATE 2
32 0016906016 BOLT, HEX HEAD 12
33 M2463200203 DUCT 1
33A M2493502104 ACOUSTIC SHEET 1
34 0016908020 BOLT, HEX HEAD 10
35 M2463400003 DUCT COVER 1
36 0016908020 BOLT, HEX HEAD 6
37 M2423200814 OVER COVER, FRONT FRAME 1
37A M2493102604 ACOUSTIC SHEET 1
38 0016908020 BOLT, HEX HEAD .............................................. 49 ........ 8300001~8300020
38 0019208020 BOLT, HEX HEAD .............................................. 49 ........ S/N 8300021~
39 0016910025 BOLT, HEX HEAD ................................................8 ........ S/N 8300001~8300020
39 0019210025 BOLT, HEX HEAD ................................................8 ........ S/N 8300021~
40 M3310600004 COVER, RADIATOR CAP 1
41 0016908020 BOLT, HEX HEAD ................................................4 ........ S/N 8300001~8300020
41 0019208020 BOLT, HEX HEAD ................................................4 ........ S/N 8300021~
42 0016908020 BOLT, HEX HEAD 6
43 M2483100004 COVER, EXHAUST PIPE 1
44 0016908020 BOLT, HEX HEAD 2
45 0016908020 BOLT, HEX HEAD 1
45A 004050800 TOOTHED WASHER 1
46 0605503062 FUEL LEAK DETECTED SWITCH 1
47 M1414800104 BRACKET 1
48 0016908020 BOLT, HEX HEAD 2
DCA-70USJ — ENCLOSURE #1 ASSY.
THE SERIAL NUMBER MAY BE REQUIRED.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE 5-BLACK
2-WHITE 6-CATERPILLAR YELLOW
3-SPECTRUM GREY 7-CATO GOLD
4-SUNBELT GREEN 8-RED
