DCA-70USJ — OPERATION AND PARTS MANUAL — REV. #0 (09/16/04) — PAGE 75
1
DCA-70USJ — ENCLOSURE #1 ASSY.
ENCLOSURE #1 ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2413001502 BASE 1
2 M2363300203 ENVIRONMENTAL TANK 1
3 0016910030 BOLT, HEX HEAD 12
4 0603306797 PLUG 1
5 M2423000912 FRONT FRAME 1
5A M2493104103 ACOUSTIC SHEET 1
6 M2423001002 FRONT FRAME 1
6A M2493104103 ACOUSTIC SHEET 1
8 0601850100 GROMMET 1
9 0016908020 BOLT, HEX HEAD 26
10 0016910025 BOLT, HEX HEAD 6
11-1 M3131400103 HOSE COVER 1
11-2 M3131400004 HOSE COVER 1
12 0016908020 BOLT, HEX HEAD 13
13 M3423500104 BRACKET 1
14 0016906016 BOLT, HEX HEAD 6
15 M3423200704 DUCT COVER 2
16 0016906020 BOLT, HEX HEAD 14
17 M3423200804 DUCT COVER 1
18 0016906016 BOLT, HEX HEAD 6
19 M2310300204 FAN SHROUD 1
20 M2310300304 FAN SHROUD 1
21 0016906020 BOLT, HEX HEAD 14
22 M2423300004 DISCHARGE GUIDE 1
22A M2493600004 ACOUSTIC SHEET 1
23 0016908020 BOLT, HEX HEAD 6
24 M2423201303 COVER, FRONT FRAME 1
24A M2493103404 ACOUSTIC SHEET 1
25 0016908020 BOLT, HEX HEAD .............................................. 27 ........ S/N 8300001~8300020
25 0019208020 BOLT, HEX HEAD .............................................. 27 ........ S/N 8300021~
26 M3433000813 CENTER FRAME 1
26A M3493201204 ACOUSTIC SHEET 1
27 0010114040 BOLT, HEX HEAD 4
27A 0030014000 HEX, NUT 4
27B 0040014000 SPRING WASHER 4
27C 0041214000 PLAIN WASHER 8
THE SERIAL NUMBER MAY BE REQUIRED.
ADD THE FOLLOWING DIGITS AFTER THE PART
NUMBER WHEN ORDERING ANY PAINTED PANEL TO
INDICATE COLOR OF UNIT:
1-ORANGE 5-BLACK
2-WHITE 6-CATERPILLAR YELLOW
3-SPECTRUM GREY 7-CATO GOLD
4-SUNBELT GREEN 8-RED
