DCA-150USJ — OPERATION AND PARTS MANUAL — REV. #1 (01/15/08) — PAGE 77
1
DCA-150USJ — ENCLOSURE #1 ASSY.
THE SERIAL NUMBER MAY BE REQUIRED.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE 5-BLACK
2-WHITE 6-CATERPILLAR YELLOW
3-SPECTRUM GREY 7-CATO GOLD
4-SUNBELT GREEN 8-RED
ENCLOSURE #1 ASSY.
NO. PART NO. PART NAME QTY. REMARKS
26 0010120050 HEX, HEAD BOLT 4
26A 0030020000 HEX, NUT 4
26B 0040020000 SPRING WASHER 4
26C 0041220000 PLAIN WASHER 8
27 M3463101002 ROOF PANEL 1
27A M3493505804 ACOUSTIC SHEET 1
28 M3463201202 ROOF PANEL 1
28A M3493506903 ACOUSTIC SHEET 1
29 M3463201104 BACK PLATE 2
30 0016906016 HEX, HEAD BOLT 12
31 M3463201303 DUCT 1
31A M3493506004 ACOUSTIC SHEET 1
32 016908020 HEX, HEAD BOLT 10
33 M3463400103 DUCT COVER 1
34 0016908020 HEX, HEAD BOLT 6
35 M3423200604 OVER COVER, FRONT FRAME 1
35A M3493108004 ACOUSTIC SHEET 1
36 0019208020 HEX, HEAD BOLT 49
37 0019210025 HEX, HEAD BOLT 8
38 M3310600004 COVER, RADIATOR CAP 1
39 0019208020 HEX, HEAD BOLT 4
40 0016908020 HEX, HEAD BOLT 6
41 M3483100204 COVER, EXHAUST PIPE 1
42 0016908020 HEX, HEAD BOLT 2
43 0016908020 HEX, HEAD BOLT 1
43A 0040508000 TOOTHED WASHER 1
44 0605503062 FUEL LEAK DETECTED SWITCH 1
45 M3366600104 BRACKET 1
46 0017108020 HEX, HEAD BOLT 2
