DCA-150USJ — OPERATION AND PARTS MANUAL — REV. #1 (01/15/08) — PAGE 75
1
DCA-150USJ — ENCLOSURE #1 ASSY.
THE SERIAL NUMBER MAY BE REQUIRED.
ADD THE FOLLOWING DIGITS AFTER THE PART
NUMBER WHEN ORDERING ANY PAINTED PANEL TO
INDICATE COLOR OF UNIT:
1-ORANGE 5-BLACK
2-WHITE 6-CATERPILLAR YELLOW
3-SPECTRUM GREY 7-CATO GOLD
4-SUNBELT GREEN 8-RED
ENCLOSURE #1 ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M3413002002 BASE 1
2 M3363300403 ENVIRONMENTAL TANK 1
3 0016910030 HEX, HEAD BOLT 12
4 0603306797 PLUG ...................................................................1 ........ 1 1/2
5 M3423001802 FRONT FRAME 1
5A M3493110703 ACOUSTIC SHEET 1
6 M3423001902 FRONT FRAME 1
6A M3493110703 ACOUSTIC SHEET 1
7 0601850100 GROMMET ..........................................................1 ........ G-1
8 0016908020 HEX, HEAD BOLT 26
9 0016910025 HEX, HEAD BOLT 6
10 M3131400503 HOSE COVER 1
11 0016906020 HEX, HEAD BOLT 7
12 M3131400404 HOSE COVER 1
13 0016906020 HEX, HEAD BOLT 8
14 M3423500104 BRACKET 1
15 0016906020 HEX, HEAD BOLT 6
16 M3423200704 DUCT COVER 2
17 0016906020 HEX, HEAD BOLT 14
18 M3310300404 SHROUD BRACKET 1
19 0016906016 HEX, HEAD BOLT 11
20 M3423300104 DISCHARGE GUIDE 1
20A M3493600304 ACOUSTIC SHEET 1
21 0016908020 HEX, HEAD BOLT 6
22 M3423201103 COVER, FRONT FRAME 1
22A M3493110804 ACOUSTIC SHEET 1
23 0019208020 HEX, HEAD BOLT 26
24 M3433000813 CENTER FRAME 1
24A M3493201004 ACOUSTIC SHEET 1
25 0010114040 HEX, HEAD BOLT 4
25A 0030014000 HEX, NUT 4
25B 0040014000 SPRING WASHER 4
25C 0041214000 PLAIN WASHER 8
