TRAK-14 — OPERATION & PARTS MANUAL — REV. #2 (09/07/04) — PAGE 25
Figure 17. Engine Oil Dipstick (Removal)
3. Insert and remove the dipstick without screwing it into the filler
neck. Check the oil level shown on the dipstick.
4. If the oil level is low (Figure 18), fill to the edge of the oil filler
hole with the recommended oil type (Table 5). Maximum oil
capacity is 0.63 quarts (0.60 liters)
Figure 18. Engine Oil Dipstick (Oil Level)
Before Starting
1.
Read safety instructions at the
beginning of manual.
2.
Clean the saw, removing dirt and
dust, particularly the engine
cooling air inlet, carburetor and air
cleaner.
3.
Check the air filter for dirt and dust. If air filter is dirty, replace
air filter with a new one as required.
4.
Check carburetor for external dirt and dust. Clean with dry
compressed air.
5.
Check fastening nuts and bolts for tightness.
Engine Oil Check
1.
To check the engine oil level, place the saw on a secure
level surface with the engine stopped.
2.
Remove the filler dipstick from the engine oil filler hole
(Figure 17) and wipe clean.
Fuel Check
1. Remove the gasoline cap located on top of fuel tank.
2. Visually inspect to see if the fuel level is low. If fuel is low,
replenish with unleaded fuel.
3. When refueling, be sure to use a strainer for filtration. DO
NOT top-off fuel. Wipe up any spilled fuel
immediately!
Explosive Fuel
DANGER
DANGER
DANGER
DANGER
DANGER
Motor fuels are highly flammable and can be
dangerous if mishandled. DO NOT smoke
while refueling. DO NOT attempt to refuel the
pump if the engine is
hot!
or
running
.
e
p
y
T
li
O
.
5
e
l
b
a
T
n
o
s
a
e
S
e
r
u
t
a
r
e
p
m
e
T
e
p
y
T
li
O
r
e
m
m
u
S
r
e
h
g
i
H
r
o
C
°
5
2
0
3
-
W
0
1
E
A
S
ll
a
F
/
g
n
i
r
p
S
C
°
0
1
~
C
°
5
2
0
2
/
0
3
-
W
0
1
E
A
S
r
e
t
n
i
W
r
e
w
o
L
r
o
C
°
0
0
1
-
W
0
1
E
A
S
TRAK 14 — PRE-SETUP (GASOLINE)
