PAGE 22 — HS62A CUT-OFF SAW — OPERATION & PARTS MANUAL — REV. #1 (07/26/10)

Figure 19. Re-Installing Cover Guard

Re-install the

guard



and

V-belt



covers

. Fully tighten

the two cap screws



and reinstall the adjustment knob



Re-tension the V-belt by turning the

belt tensioning cam



The V-belt should remain in tension.

Fully tighten the three nuts



that lock the V-belt into the proper

tensioning position.

Figure 18. Reversing the Cutting Arm

HS62A CUT-OFF SAW — MAINTENANCE

V-Belt Changing Procedure (continued)
