PAGE 14 — G-55H GASOLINE VIBRATOR — OPERATION & PARTS MANUAL — REV. #0 (03/07/06)
Figure 4. Engine Oil Dipstick (Removal)
Reference manufacturer engine
manual for specific servicing
instructions.
Figure 5. Engine Oil Dipstick (Oil Level)
Engine Oil Check
1.
To check the engine oil level, place the vibrator on
secure level ground with the engine stopped.
2.
Remove the filler dipstick from the engine oil filler hole
(Figure 4) and wipe clean.
e
p
y
T
li
O
.
3
e
l
b
a
T
n
o
s
a
e
S
e
r
u
t
a
r
e
p
m
e
T
e
p
y
T
li
O
r
e
m
m
u
S
r
e
h
g
i
H
r
o
C
°
5
2
0
3
-
W
0
1
E
A
S
ll
a
F
/
g
n
ir
p
S
C
°
0
1
~
C
°
5
2
0
2
/
0
3
-
W
0
1
E
A
S
r
e
t
n
i
W
r
e
w
o
L
r
o
C
°
0
0
1
-
W
0
1
E
A
S
LOWER LIMIT
G-55H GASOLINE VIBRATOR — INSPECTION
NEVER place hands or feet inside the belt
guard cover while the engine is running.
ALWAYS shut the engine down before
performing any kind of maintenance
service on the unit.
Inspection &
Maintenance Saftey
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
ALWAYS wear approved eye and
hearing protection before inspecting,
operating or servicing the vibrator.
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
Eyesight and Hearing
Protection
Before Starting
Before starting and operating the G-55H Gasoline Vibrator,
perform the following:
■
Read safety instructions at the beginning of manual.
■
Clean the vibrator, removing dirt and dust, particularly
the engine cooling air inlet, carburetor and air cleaner.
■
Check the air filter for dirt and dust. If air filter is dirty,
replace air filter with a new one as required.
■
Check carburetor for external dirt and dust. Clean with
dry compressed air.
■
Check fastening nuts and bolts for tightness.
■
Check the engine oil level of the engine.
■
Check the fuel level of the engine.
■
Check the tension and condition of the vibrator power
unit's V-belts.
3. Insert and remove the dipstick without screwing it into
the filler neck. Check the oil level shown on the dipstick.
4. If the oil level is low (Figure 5), fill to the edge of the oil
filler hole with the recommended oil type (Table 3).
Maximum oil capacity is 0.63 quarts (.60 liters).
NOTE
UPPER LIMIT
