page 4 — MgX SerieS • operaTion and parTS Manual — rev. #0 (03/26/12)

table Of cOntents

MGX series concrete vibrator

Silicosis/Respiratory Warnings ................................ 3

Table Of Contents .................................................... 4

Parts Ordering Procedures ...................................... 5

Safety Information ................................................ 6-9

Specifications ........................................................ 10

Dimensions ............................................................ 11

General Information .......................................... 12-13

Components .......................................................... 14

Operation ............................................................... 15

Maintenance ..................................................... 16-18

Troubleshooting ..................................................... 19

Explanation Of Code In Remarks Column............. 20

Suggested Spare Parts ......................................... 21

component drawings

Motor Assy. ....................................................... 22-23

Shaft/Head Assy. .............................................. 24-27

Terms And Conditions Of Sale — Parts ................ 28

NOTICE

Specifications and part numbers are subject to change

without notice.
