PAGE 44 — SCT SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #4 (04/02/07)
SCT SERIES TROWEL — GEARBOX ASSY.
GEARBOX ASSY.
1
2
7
6
3
4
5
1 2
3
4
5
6
6
7
7
9
10
11
12
16
17
18
18
19
19
20
21
22
23
24
30
31
31
32
32
33
34
36
25
26
29
27
28
13
35
14
15
8
3
2
1
4
5
6
7
TORQUE TO 15 LB/FT.
APPLY SEALANT (LOCTITE
572 OR EQUIVALENT).
APPLY THREAD LOCK (LOCTITE
242 BLUE OR EQUIVALENT).
SHIM AS NECESSARY
FOR 0.005 TO 0.010
INTPUT SHAFT ENDPLAY.
SHIM AS NECESSARY
FOR 0.000 TO 0.003
OUTPUT SHAFT ENDPLAY.
USE SPECIALLY FORMULATED
WHITEMAN GEARBOX LUBRICANT
P/N 10139 OR ISO 680 OIL.
GUARD RING.
39
38
37 GEARBOX ASSEMBLY
GASKET/SEAL KIT
BEARING KIT
GEARBOX
OIL
22 0Z.
QTY. 1
GEARBOX REQUIRES
22 OZ. OF LUBRICATING
OIL FOR OPERATION.
