EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 15
EPOXY/M SERIES TROWEL— SPECIFICATIONS (TROWEL)
NOTE:
1.
Sound pressure is a weighted measure. Measured at the
operators ear position while the walk-behind trowel is
operating at full throttle on concrete in a manner most often
experienced in “
normal
” circumstances. Sound pressure
may vary depending upon the condition of the concrete.
Hearing protection is always recommended.
Figure 2. EPOXY/M SERIES Trowel
Dimensions
2.
The vibration level indicated is the maximum RMS (Root
Mean Square) value obtained at the handle grip while
operating the walk-behind trowel on curing concrete in a
manner most often experienced in “
normal
” circumstances.
Values were obtained from all three axes of motion. The
values shown represent the maximum RMS value from
these measurements.
