JA-SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #9 (07/02/10) — PAGE 55
NO. PART NO. PART NAME QTY. REMARKS
30 1150 ARM, YOKE 1
31 20802 RING, SNAP, TRUARC 5100-37 OR EQUIV. 2
32 20803 SPACER, .50 OD X .40 ID X 0.25L 2
33 20801 PIN, YOKE 1
34 20796 GUARD RING ASSY., JA 1
36 1954 FRONT ENGINE MOUNT 1
37 1942 REAR ENGINE MOUNT 1
38 1247 GROMMET 1/4 X .875 ID X 1-5/8 OD 4
39 1245 SPACER, GUARD RING 4
40 20394 GEARBOX ASSY., JA ............................................ 1 .................. INCLUDES ITEMS W/%
41 21046 GASKET/SEAL KIT. ............................................... 1 .................. INCLUDES ITEMS W/ *
42 21047 BEARING KIT KIT. ................................................. 1 .................. INCLUDES ITEMS W/#
43 10139 GEARBOX OIL, 22 OZ. 1
JA-SERIES TROWEL — GEARBOX AND ENGINE MOUNTS ASSY.
