JWN ride-oN troWel • parts maNual — rev. #0 (08/15/11) — page 5
suGGEstED sParE Parts
JWN24 series ride-oN troWel, HoNda
gx690rtaf-r280 24 Hp eNgiNe
1 to 3 units
Qty. p/N description
4............20409 ............... TROWEL ARM, (L.S.)
4............20408 ............... TROWEL ARM, (R.S.)
4............1163 ................. LEVER TROWEL ARM (R.S.)
4............1555 ................. LEVER TROWEL ARM (L.S.)
2............10968 ............... THRUST COLLAR KIT
2............20369 ............... SPIDER ASSY., 4-BLADE (L.S.)
2............20370 ............... SPIDER ASSY., 4-BLADE (R.S.)
20..........0166 A ............. WASHER, SPIDER
20..........1876 ................. JAM NUT, SPIDER
20..........0164 B ............. SCREW, SPIDER
4............1157 A ............. BUSHING, SPIDER
4............1316 ................. SPRING, SPIDER (L.S.)
4............1317 ................. SPRING, SPIDER (R.S.)
20..........1875 ................. WASHER, SPIDER
20..........1322 ................. SCREW ASSY., ARM
....................................... RETAINING, SPIDER
20..........1162 A ............. CAP GREASE FITTING, SPIDER
1............23513 ............... BELT, DRIVE CVT
1............23514 ............... FUEL CAP/GAUGE (ENGINE)
1............23518 ............... CABLE, THROTTLE (FOOT PEDAL)
6............2064 ................. ROD END, FEM RH 3/8-24
....................................... (STEERING)
4............2063 ................. ROD END, MALE RH 3/8-24
....................................... (STEERING)
2............11142 ............... ROD END, MALE RH 1/2-20
....................................... (STEERING)
NOTICE
Part numbers on this Suggested Spare Parts list may
supersede/replace the part numbers shown in the
following parts lists.
Qty. p/N description
10..........10031 ....................WASHER 1/4 IN.
1............23434 ....................SPRAY PUMP
1............392292 ..................SPRAY NOZZEL
1............29509 ....................CAP, SPRAY TANK
1............406000 ..................ROCKER SWITCH (LIGHTS)
1............39700Z6L003 .......HOUR METER
1............21870 ....................KILL SWITCH, (SEAT)
1............12017 ....................RELAY, KILL (SEAT)
3............20111 ....................OIL, GEARBOx
1............2618 ......................GASKET AND SEAL KIT (GB)
1............12833 ....................BEARING KIT (GEARBOx)
2............17210Z6L010 .......ELEMENT COMP. A/C
1............17218Z6L000 .......FILTER, OUTER A/C
2............16910Z6L003 .......STRAINER COMP. FUEL
1............35110ZV5V50 .......KEY ASSY.
1............37240ZG5004 .......SWITCH, OIL PRESSURE
3............15400PLMA01PE .CARTRIDGE, OIL FILTER
4............980795587G .........SPARK PLUG
2............23284-030 ............FUSE, 3A
2............23284-150 ............FUSE, 15A
2............982004300 ............FUSE, 30A
2............22347 ....................LIGHT, HELLA
4............BLADE ASSY. ......CONTACT UNIT SALES
............................................DEPT/ACCESSORY ITEM
