JWN ride-oN troWel • parts maNual — rev. #0 (08/15/11) — page 29
sPIDEr assY. (lEFt)
NO. PART NO. part Name QTY. remarKs
1 10968 THRUST COLLAR ASSY, JB SEALED ..............1................INCLUDES ITEMS W/@
2@ 12778 BEARING, THRUST 6013-2RS 1
3@ 12208 WEAR RING, SEALED THRUST 1
4@ 39A1796 CASTING, THRUST COLLAR J & B 1
5@ 1471 BUSHING, BRONZE 1
6@ 1154 A PLATE, WEAR 1
7 20369 SPIDER ASSY, 4BLD LEFT SIDE ....................1................INCLUDES ITEMS W/%
8% 22646 SPIDER HUB ASSY 1
9% 1162 A CAP, GREASE ZERK, #2 YELLOW 4
10% A5978 SCREW, ARM RETAINING 4
11% 1875 WASHER, INT. SHKP, 3/8 4
12% 11602 SCREW, SHS 3/8-16 x.25 4
13% 1456 NUT, HEx FINISH 3/8-16 1
14% 12097 SCREW, SQHS 3/8-16x1-3/4 CONE GRD 8 1
15% 1316 SPRING, LS J/B ARM RETURN 4
16% 1157 A BUSHING, INSERT 4
17% 0164 B SCREW, HHC ROUNDED 4
18% 1876 NUT, HEx JAM 3/8-16 CLASS 2B 4
19% 0166 A WASHER, LOCK, 3/8 MED. 4
20% 1555 LEVER, TROWEL ARM, LEFT HAND 4
21% 4164 PIN, ROLL 5/16x 1-3/4,NO PLATE 4
22% 20409 ARM, TROWEL BLADE JWN LEFT 4
23% 9193 KEY, SQ RN .312x3.00 1
