page 12 — JWN ride-oN troWel • parts maNual — rev. #0 (08/15/11)
stEErInG cOntrOl assY.
1
ITEM 25 P/N 7798 STEERING ASSY.,
INCLUDES STEERING HANDLES AND
STEERING CONTROL ASSEMBLIES.
NOTES:
2
REFERENCE STEERING HANDLES ASSY.
ON NEXT PAGE.
PART OF
FRAME
LEFT-SIDE
3
3
LOWER RIGHT-SIDE STEERING
CONTROL ASSY. IS THE SAME AS
LEFT-SIDE STEERING CONTROL
ASSY.
1
4
COMPRESS
SPRING TO:
4.90 ~ 4.80 IN.
12.4 ~12.1 CM.
26
27
28
29
30
31
32
33
4
