JTNS/SW20H RIDe-ON pOWeR TROWeL• paRTS maNuaL — Rev. #1 (11/08/13) — page 43
sPiDeR assY. (RigHT)
NO
PART NO
paRT Name
QTY.
RemaRKS
1$
12208
WEAR RING
1
2$
12778
FLANGE BEARING
1
3$
10793
THRUST COLLAR W/ BUSHING ......................1................INCLUDES ITEM W/%
4$% 1471
BUSHING
1
5$
1154 A
LOWER WEAR PLATE
1
6
10968
THRUST BEARING KIT .....................................1................INCLUDES ITEMS W/$
7#
24227
CAP, GREASE ZERK
4
11#
0164 B
SCREW, HHC 3/8-16 X 1-1/4" ROUNDED.
4
12#
0166 A
WASHER, LOCK, 3/8" MED.
4
13#
1157 A
BUSHING,TROWEL SMALL ARM
4
14#
1317
SPRING, R.S. ARM RETURN
4
15#
11602
SCREW, HHC 3/8-16 X 3/8"
4
16#
11876-G
SPIDER PLATE, 1-1/8" SHAFT, 4-BLD, GREEN 1
17#
1322
SCREW, RETAINING
4
18#
1875
WASHER, INT. SHKP, 3/8"
4
19#
1876
NUT, HEX JAM 3/8-16
4
20#
1555-G
LEVER, TROWEL, LH, GREEN
4
21#
2826-G
ARM, TROWEL 9-3/4", GREEN
4
22#
4164
PIN, ROLL 5/16" X 2"
4
25
24270
SPIDER ASSY, 4BLD, RS. .................................1................INCLUDES ITEMS W/#
26
0105
SCREW, HHC 5/16-18 X 1-1/2"
4
27
0161 C
LOCK WASHER 5/16"
8
28#
12097
SCREW, SQHS 3/8-16x1-3/4" GRD 8
1
29#
1456
NUT, HEX 3/8-16
1
30
60091
LOCTITE, #242 BLUE
1
31
1141
KEY, 5/16" SQ X 2-5/8"
1
