JTNS/SW20H RIDe-ON pOWeR TROWeL• paRTS maNuaL — Rev. #1 (11/08/13) — page 37
engine mounTing anD CluTCH assY.
NO.
paRT NO.
paRT Name
QTY.
RemaRKS
1
0166 A
WASHER, LOCK, 3/8" MED.
1
2
0181 B
WASHER, LOCK 1/4" MED
2
3
0300 A
SCREW, HHC 5/16-18" X 2"
4
4
0300 B
WASHER, FLAT SAE 5/16"
8
5
0310
KEY, 1/4" SQ X 1-1/2"
1
6
0448
WASHER, FLAT SAE 7/16"
4
7
0948
WASHER, FLAT SAE 1/4"
2
8
2667
SCREW, HHC 3/8-24 X 2-1/2"
1
9
24174
NUT, "U" TYPE, M8 X 1.25
3
10
4514
SCREW, HHC 1/4-20 X 5/8" GRD 5
2
11
5283
NUT, NYLOC 5/16-18"
4
12
9123
DRIVE PULLEY RETAINER
1
13 10948 SPACER
1
14
10984
SPACER, ENGINE MOUNT
2
15
11064
BELT, A36, GATES HP-II
4
16
24172
BACK PANEL, BELT GUARD
1
17
24252
SCREW, HHC 7/16-14 X 0.75"
4
18
19266
NUT, BLIND 1/4-20 X .027-.165
2
19
22021
SCREW,HEX FLANGE M8-1.25 x 20MM GRD10
3
20
24171
BELT GUARDT
1
21
24106
BELT HOLDER, SPARE BELT
1
22
60097
LOCTITE, #246 BLUE
1
23
24143
CLUTCH, 35°, 4" POS-GRIP ASSY, 1" BORE ....................1..........INCLUDES ITEMS W/$
24$
1893
SCREW, SHS 3/8-24 X 5/8", ZINC PLATED
2
25$
24155
CLUTCH PLATE ASSY. 35° W/ BEARINGS
1
26$
2504
BOWL, CLUTCH 35°
1
27$
2450
WEIGHT SPRING, 4" CLUTCH
2
28$
2451
WEIGHT, 4" POSI GRIP CLUTCH
4
29$
1886
PULLEY, CLUTCH CENTER SLIDER, 4"
1
30$
1882
STEM CLUTCH ASSEMBLY
1
