JTNS/SW20H RIDe-ON pOWeR TROWeL• paRTS maNuaL — Rev. #1 (11/08/13) — page 27
PiTCH ConTRol ToWeR assY.
NO.
paRT NO.
paRT Name
QTY.
RemaRKS
1$#
1116
NUT, BRASS JAM 5/16-18
2
2$#
36720
SCREW, HHF 5/16-18 X 3/4" GRD5
4
3$#
23582
TOWER, PITCH CONTROL .................................................1..........RIGHT SIDE
3$#
23581
TOWER, PITCH CONTROL .................................................1..........LEFT SIDE
4$#
2008
CABLE ASSY, 25.63"
1
6$#
2156
SPRING, HANDLE BALANCE COIL
1
7$#
10721
SLIDE BLOCK, PITCH CONTROL .......................................1..........RIGHT SIDE
7$#
10722
SLIDE BLOCK, PITCH CONTROL .......................................1..........LEFT SIDE
8$#
10723
PIN, SPIRAL 3/16 X 1-3/8"
1
9$#
24112
PIN, ADJUSTMENT
1
10$#
24113
SHAFT, PITCH CONTROL ...................................................1..........RIGHT SIDE
10$#
24114
SHAFT, PITCH CONTROL ...................................................1..........LEFT SIDE
11$#
0627
KEY, 3/16" X 1-1/4"
1
12$#
24109
COLLAR, SET
1
13$#
24115
SCREW, SET, 5/16-18 X 1/4"
2
14$#
2170
BEARING, RACE
2
15$#
2169
BEARING, THRUST
1
16$#
1612
BEARING, ALUM., PITCH CONTROL
1
17$#
0281
BEARING, THRUST
1
19$#
10512
RING, SNAP
1
20$#
22021
SCREW, HHFS M8-1.25 X 20 MM, GRD10.9, .................... 2 .........RIGHT SIDE
21$#
24107
HOUSING, PITCH CONTROL
1
22$#
22021
SCREW, HHFS M8-1.25 X 20 MM, GRD10.9, PATCH .........1..........LEFT SIDE
23$#
17109
SCREW, SHSCU M8-1.25 X 8MM
1
24%$#
2621
FITTING, GREASE ZERK STR.
2
25%$#
24227
CAP, GREASE ZERK
2
26$#
24105
GEAR, DRIVE PITCH CONTROL
1
27$#
2649
COVER, PITCH CONTROL HOUSING
1
28%$#
0185
SCREW, SHS 3/8-16 X 3/8
1
29$#
9191
SCREW, BHSC M5-0.8 X 16MM
4
