HHXD5 RIDe-ON TROWeL • paRTs maNuaL — Rev. #3 (07/24/13) — page 9
NO. paRT NO. paRT Name QTY. RemaRKs
1 21852 SEAT, MICHIGAN ADJuSTABLE W/ ARMS .............. 1 .............INCLuDES ITEMS W/@
2@ 21860 SEAT, MICHIGAN, BASIC 1
3@ 21868 ARM REST KIT, MICHIGAN V-2805 SEAT ................ 2 .............INCLuDES ITEMS W/%
4@% 21869 SCREW, CAP 5/16-18 X 5/8" 6
5@ 21865 SEAT ADJuSTER KIT, MICHIGAN V-2805 SEAT 1
6@ 32980 SWITCH, KILL, DELTA SYSTEMS 6440-62 1
7 21936 CONNECTOR BODY, 2 PIN MICHIGAN SEAT 1
8 21924 WIRE ASSY, 16 GA RED X 11" 1
9 21923 WIRE ASSY, 16 GA VIOLET/ORANGE X 12.5" 1
10 21597 BuMPER STEM 1.0" D X .5 X .31 3
11 19468 GROMMET, MINOR-PNZ 4004 1
12 23080 PLATE, OPERATOR SEAT 1
13 23281 SHIELD, SEAT PLATE 1
14 0106 NuT, HEX JAM 5/16-18 4
15 0300 B WASHER, FLAT SAE 5/16 4
16 5283 NuT, NYLOC 5/16-18 4
17 23204 PANEL, FRONT 1
18 12287 SCREW, THP 1/4-20 X 3/4 SS 19
19 19266 NuT, BLIND 1/4-20 X 10GA 12
20 23047 SuBFRAME, INNER SEAT 2
21 23296 NuT, 3/8-16 J-TYPE RETAINER 4
22 20909 SCREW, HHC 1/4-20 X 2 4
23 20685 BLOCK, OPERATOR SEAT PIVOT 2
24 22228 SCREW, HHF 3/8-16 X 1 GRD 8 4
25 23126 PANEL, REAR ENGINE 1
26 23297 MANuAL HOLDER, PICTOGRAPH SAE J232 1
SEat fRaME aSSY.
