HHXD5 RIDe-ON TROWeL • paRTs maNuaL — Rev. #3 (07/24/13) — page 39
DRIVE aSSY. (nEw StYLE)
NO. paRT NO. paRT Name QTY. RemaRKs
1 23140 SHAFT, DRIVE CV JOINT ASSY ....................................2 ....... INCLuDES ITEMS W/@
2@ 2090 SNAP RING, TRuARC#5100-106 1.062 DIA X .056 2
3@ 392052 C.V. JOINT, COuPLING 2
4@ 11108 GASKET, C.V. JOINT BOOT RIDERS 2
5@ 2259 BOOT ASSY, C.V. JOINT RIDERS ..................................2 ....... INCLuDES ITEMS W/#
6@# 22219 O-RING, SIZE 2-228N-90 2.25 DIA X .125 2
7@# 22220 O-RING, SIZE 2-225N-90 1.875 DIA. X .125 2
8@ 1662 TIE, CABLE TY-RAP BLACK 2
9@ 23150 SHAFT, C.V. JOINT 7.70LG 1
10@ 0126 KEY, WOODRuFF #606 3/16 X 3/4 (#9) 2
11 23425 DRIVE, CROSS SHAFT ASSY .......................................1 ....... INCLuDES ITEMS W/%
12% 1146 SCREW, FHSC 5/16-18X1, NYLON, NP 1
13% 2037 SPACER, CSK 1.375 DIA. X .328 DIA. X .250 1
15% 23162 COuPLER, C.V. SHAFT DRIVE 1
16% 10909 KEY, SQ 3/16 X 11/16 1
17% 23423 SHAFT, DRIVE BEARING 1
18% 10337 BEARING, P-BLOCK 1.0" - JIB #VPLS205-16 2
19% 23424 SPACER, 1.25 DIA. X 1.01 DIA. X 6.28" 1
20 23363-2 PuLLEY, CVT DRIVEN HILLIARD 1
21 20116 O-RING, SIZE-031 BuNA N 1
22 23420 COuPLER, DRIVEN CCVT 1
23% 11773 SHIM, STEEL .031 X 1.5 DIA. X 1.0 XIA. 2
24% 20363 KEY, STEEL .188 X .250 X 2.5 1
25 9165 SCREW, HHFS 1/4-28 X 3/4 GR5 PATCH 3
26 2186 SCREW, SHC 5/16-16 X 2-1/4 PLTD 9
27 0161 C WASHER, LOCK, 5/16 MED 12
29 11772 SHIM, TRuNNION .063 A/R
30 0243 SCREW, SHC 5/16- 18 X 1-3/4 3
31 23305 SCREW, HHF M12-1.75X30MM GR8.8 PATCH 4
32 9092 SCREW, FHSC 5/16-18X1.25, NYLON PATCH 1
NOTICE
Multi-Clutch components are not interchangeable with the prior Hoffco
Comet drive system. The Hoffco Comet CVT system must be replaced
with Multi-Clutch components in the event of a Hoffco Comet clutch failure.
