HHXD5 RIDe-ON TROWeL • paRTs maNuaL — Rev. #3 (07/24/13) — page 5
SuggEStED SpaRE paRtS
HHXD5 RIDe-ON TROWeL WITH b & s vaNguaRD Dm950bT DIeseL eNgINe
1 to 3 units
Qty. p/N Description
3............23284-100 ............FuSE, 10 AMP ATC/ATO
3............23284-300 ............FuSE, 30 AMP ATC/ATO
1............12017 ....................RELAY,KILL # HELLA # 87411B
1............406000 ..................ROCKER, LIGHT SWITCH, ON-OFF
1............20165 ....................PALM HANDLE KIT, L/R HANDLES W/O BOOT
2............12548 ....................PuMP, SPRAY, SHuRFLO 100-000-21
1............1714 ......................CABLE ASSY, 43.75
3............22347 ....................LIGHT, HELLA 50W BOTTOM MOuNT #996361617
1............23152 ....................CABLE, THROTTLE
2............2829 ......................ARM, TROWEL HD EXTENDED
6............11039 ....................BuSHING, TROWEL LARGE ARM
3............9111 ......................SPRING, LS H ARM RETuRN STD BOSS
3............2143 ......................SPRING, RS H ARM RETuRN STD BOSS
1............21208 ....................SPIDER KIT, 5BLD HHN SERVICE KIT
2............20938 ....................THRuST ASM, SERVICE HTH, HHN, HTO TROWELS
1............23262 ....................CYLINDER, HYDRAuLIC STEERING ASSY
1............23275-02 ..............ELEMENT, 10 MICRON FILTER
2............820314 ..................OIL FILTER
2............23014-12 ..............FuEL FILTER
2............M113621 ...............AIR CLEANER ELEMENT
1............22408 ....................GAuGE, MuLTI
2............821075 ..................V-BELT, ENGINE
2............20138 ....................BELT, CVT CLuTCH COMET #302609 DF
2............23365 ....................BELT, CVT MuLTI-CLuTCH
1............10958 ....................SWITCH, IGNITION, HONDA/VANGuARD TWINS, W/KEYS
1............821135 ..................SWITCH, OIL PRESSuRE
1............23014-03 ..............SWITCH, WATER TEMPERATuRE
1............825064 ..................THERMOSTAT
1............23312 ....................HOSE, RADIATOR, uPPER
1............825133 ..................HOSE, RADIATOR, LOWER
NOTICE
Part numbers on this Suggested Spare Parts list may
supersede/replace the part numbers shown in the
following parts lists.
