HHNg5 Ride-oN tRowel• paRts maNual — Rev. #2 (06/06/14) — page 41
SEAt AnD fRAME ASSY.
No. paRt No. paRt Name QtY. RemaRKs
1 21861 SEAT, MICHIGAN ADJUSTABLE W/O ARMS ........... 1 .............INCLUDES ITEMS W/@
2@ 21860 SEAT, MICHIGAN, BASIC 1
3@ 21870 SWITCH, KILL 1
4@ 21865 SEAT ADJUSTER KIT ................................................ 1 .............INCLUDES ITEMS W/%
5@% 21864 SEAT ADJUSTER, RH 1
6@% 21863 SEAT ADJUSTER, LH 1
7@% 0400 B SCREW, HHC 5/16-18 X 1/2" 4
8 11472 SEAT PLATE 1
9 21597 BUMPER, STEM 1.0"D X .5S X .31 3
10 0300 B WASHER, FLAT SAE 5/16" 4
11 5283 NUT, NYLOC 5/16-18 4
12 8081 PIN, CLEvIS 1/2" X 2-3/4" 2
13 0183 PIN, COTTER 1/8"D X 1-1/4" 2
14 23932 FRAME, SEAT 1
15 30059 RIvET, POP BH .187 X .626 - .750 AL/AL 6
16 30048 SPACER, .50 OD X .206 ID 6
17 29342 WASHER, 3/16" POP-RIvET BACKUP SS 6
20 26328 NUT, FLANGED 1/2-13 SERRATED PLTD 2
21 913222 SCREW, HHC 1/2-13 X 4-3/4" 2
22 30046 HEAT SHIELD, SS, SEAT FRAME 1
23 23976 MOUNTING BASE, ADHESIvE TIE WRAP 1
24 11029 CABLE, CHOKE 60" 1
