HHNg5 Ride-oN tRowel• paRts maNual — Rev. #2 (06/06/14) — page 37
SPIDER ASSY. (RIght).
No. paRt No. paRt Name QtY. RemaRKs
1# 12779 BEARING, THRUST 6017-24S W/FLNG 1
2# 11431 THRUST COLLAR W/BUSHING ..........................................1..........INCLUDES ITEM W/$
3# 11419 PLATE, WEAR 1
4#@ 1162 A CAP, GREASE ZERK, #2 YELLOW 6
5# 2621 FITTING, GREASE ZERK STR 1/4-28 1
6@ 12931-1 SPIDER PLATE, 5BLD R.S. 1-1/2", SILvER 1
7#$ 12316 BUSHING, THRUST COLLAR W/ HOLE 1
8@ A5978 SCREW, ARM RETAINING 5
9@ 1875 WASHER, INT. SHKP, 3/8" 5
10 12687 KEY, 3/8" SQ X 2" 1
11@ 12097 SCREW, SQHS 3/8-16 X 1-3/4" CONE GRD 8 PT'D 2
12@ 1456 NUT, HEX FINISH 3/8-16 2
13@ 11039 BUSHING, TROWEL LARGE ARM 10
14@ 11602 SCREW, HHC 3/8-16 X 1/4" 5
15@ 2143 SPRING, RS H ARM RETURN STD BOSS 5
16@ 0164 B SCREW, HHC ROUNDED 3/8-16 SPCL 5
17@ 1876 NUT, HEX JAM 3/8-16 CLASS 2B 5
18@ 0166 A WASHER, LOCK, 3/8" MED. 5
19@ 11904-1 LEvER, TROWEL ARM, RIGHT, SILvER 5
20@ 9006 PIN, ROLL 5/16" X 2" NO PLATE 5
21@ 2829-1 ARM, TROWEL HD EXTENDED, SILvER 5
22 12933 SPIDER ASSY. 5 BLD R.S. 1-1/2" ........................................1..........INCLUDES ITEMS W/@
23 20938 THRUST COLLAR ASSY .....................................................1..........INCLUDES ITEMS W/#
24 60091 LOCTITE, #242 BLUE AR
