page 2 — HHNg5 Ride-oN tRowel• paRts maNual — Rev. #2 (06/06/14)
tAbLE Of COntEntS
NOTICE
Specifications and part numbers are subject to change
without notice.
hhng5 RIDE-On tROwEL
Table Of Contents .................................................... 2
Parts Ordering Procedures ...................................... 3
Explanation Of Code In Remarks Column............... 4
Suggested Spare Parts ........................................... 5
Nameplate And Decals ......................................... 6-7
Steering Control Handle Assembly ....................... 8-9
Steering Control (Assist) Assembly .................. 10-11
Pivot Assembly ................................................. 12-13
Gearbox Assembly ........................................... 14-15
Pitch Control Tower Assembly .......................... 16-17
Pitch Control Tower Assembly .......................... 18-19
Pitch Control Drive Cable Assembly ................. 20-21
Fuel Tank Assembly. ......................................... 22-23
Drive Assembly. ................................................ 24-25
Engine Mounting Assembly .............................. 26-27
Engine Clutch Assembly ................................... 28-29
Engine Components 1 ...................................... 30-31
Engine Components 2 ...................................... 32-33
Spider Assembly (Left) .................................... 34-35
Spider Assembly (Right) .................................. 36-37
Stabilizer Ring Assembly .................................. 38-39
Seat And Frame Assembly ............................... 40-41
Frame And Components Assembly .................. 42-43
Foot Pedals Assembly ...................................... 44-45
Battery Assembly.............................................. 46-47
Spray Assembly ................................................ 48-49
Lights Assembly ............................................... 50-51
Front Panel Assembly ....................................... 52-53
Top Right Control Panel Assembly ................... 54-55
Harness Assembly............................................ 56-57
E-Z Mover And Lift Handle Assembly ............... 58-59
Terms And Conditions Of Sale — Parts ........... 60-61
