WSHe/a VIBRaTORY TRUSS SCReeD • paRTS manUal — ReV. #0 (05/04/11) — page 51
wshaeXt6/12/18 end handle eXtension assy.
nO. paRT nO. paRT name QTY. RemaRkS
1+$= 0189 GRIP, hANDLE 4
2+$= 10133 NuT, NYLOC 3/8-16 4
3+$= 12220 WAShER, LOCK 1/2 hIGh STRENGTh 12
4+ 26375 6IN hANDLE ExT, AIR END 2
4$ 26378 12IN hANDLE ExT, AIR END 2
4= 26379 18IN hANDLE ExT, AIR END 2
5+$= 16195 hANDLE, SCREED 4
6+ 16630 WAShER, FLAT 1/2 SAE hARDENED 24
6$= 16630 WAShER, FLAT 1/2 SAE hARDENED 30
7+$= 1665 SCREW, hhC 3/8-16 x 2 4
11+$= 5218 SCREW, hhC 1/2-13 x 1-1/2 12
13+ 968011 NuT, hEx FINISh 1/2-13 12
13$= 968011 NuT, hEx FINISh 1/2-13 16
14$= 16073 VIbRATOR ASSY 4
15$= 26127 FITTING, 90 4Mj-2MP 4
16$= 26399 hOSE, AIR ASSY 1/4 x 36 4
17$= 26128 FITTING, TEE 1/4 FP 2
18$= 26132 FITTING, NIPPLE 1/4MP-1 2
19$= 2549 SCREW, hhC 1/2-13 x 3 4
20$= 10176 NuT, NYLOC 1/2-13 4
21 13108 WAShER, FLAT uSS 1-1/8 2
22 26153 FITTING, CROWSFOOT 3/4 MP MP 2
23 26416 FITTING, CROWSFOOT-bLANK END 1
24 26147 SAFETY CLIP, CROWSFOOT 2
25 26258 ADAPTOR, STAbILIZER END, Lh-AIR 1
26 26259 ADAPTOR, STAbILIZER END, Rh-AIR 1
27 26415 6" hANDLE ASSY .......................................... 1 .................INCLuDES ITEMS W/+
27 26392 12" hANDLE ExT ASSY ................................ 1 .................INCLuDES ITEMS W/$
27 26393 18" hANDLE ExT ASSY ................................ 1 .................INCLuDES ITEMS W/=
