WSHe/a VIBRaTORY TRUSS SCReeD • paRTS manUal — ReV. #0 (05/04/11) — page 17
nO. paRT nO. paRT name QTY. RemaRkS
1@% 10133 NuT, NYLOC 3/8-16 12
2@ 1162 A CAP, GREASE ZERK #2 6
3@ 12220 WAShER, LOCK 1/2 hIGh STRENGTh 38
4@% 13351 WAShER, FLAT 3/8 PLTD uSS hEAVY 24
5@ 16109 bLADE, 10' x 3W 1
6@ 16113 bLADE, 10' x 2W 2
7@ 16126 ANGLE, bLADE CONNECTOR 2
8@ 16141 COuPLER, DRIVE ShAFT 2
9@ 16170 bRACKET, bEARING MOuNT 1
10@ 16176 ShAFT, DRIVE 59-3/4" 2
11@ 16179 WEIGhT, ShAFT VIbRATION 8
12@ 16185 FITTING, PLuG 1/4 MP SQ hEAD 6
13@ 16194 bEARING, PILLOW bLOCK 6
14@ 16514 TuRNbuCKLE 1-5/16-16 2
15@ 16515 NuT, jAM 1-5/16-16 RIGhT hAND 2
16@ 16516 NuT, jAM 1-5/16-16 LEFT hAND 2
17@ 16630 WAShER, FLAT SAE 1/2 hIGh STRENGTh 76
18@ 16749 ZERK, GREASE 90 1/4-28 1
19@ 2691 SCREW, hhC 1/2-13 x 1 6
20@ 26047 FRAME, STEEL 5' 2
21@ 26093 KEY, .1875 SQ x 3.5 304 SS 2
22@% 26091 SCREW, ShS 1/4-28 x 1/4 8
23@ 2621 ZERK, GREASE ................................................5................INCLuDED WITh ITEM 13
24@ 26199 CAP, PIPE CAPLuGS RCL-16 1
25@ 26205 CAP, TuRNbuCKLE CAP PLuGS 14-x 1
26@ 26251 SCREW, hhC 1/4-20 x 1-1/2 GRD8 8
27@ 26252 NuT, NYLOC 1/4-20 GRD 8 8
28@ 36605 TubE ASSY, 18.0" 1
29@ 36601 TubE ASSY, 9.0" 1
30@ 3214 SCREW, hhC 1/2-13 x 1-1/4 20
31@ 5218 SCREW, hhC 1/2-13 x 1-1/2 12
32@% 1665 SCREW, hhC 3/8-16 x 2 .....................................12 ...............REPLACES P/N 9154
33@ 968011 NuT, hEx FINISh 1/2-13 38
34@% 36602 TubE ASSY, 10.5" 1
35@% 36604 TubE ASSY, 16.5" 1
36@% 36606 TubE ASSY, 28.5" 2
37@% 36589 MOuNT, TubE 6
38@% 49048 SCREW, hhFS 1/4-20 x .75 24
41@ 26073 STuD, 1/2-NC x 14 LG 2
42@ 26328 NuT, FLANGED .5 8
43@% 36597 bOLT, EYE 1/4 x 2.0" 4
44@% 36595 STRAP, TubE 2
45@% 10024 NuT, NYLOC 1/4-20 4
46@ 26075 MOuNT, bEARING 10' SECTION 1
47@% 1477 LOCTITE #242 bLuE .5CC bOTTLE 1
48 WShE100 SCREED, ENGINE 10' SECTION ASSY. ..............1 ................INCLuDES ITEMS W/@
49 36583 WShE100 CE KIT .................................................1 ................INCLuDES ITEMS W/%
wshe100 section assy.
