WSHe/a VIBRaTORY TRUSS SCReeD • paRTS manUal — ReV. #0 (05/04/11) — page 25
wsheeXt6/12/18 end handle eXtension kit
nO.
paRT nO.
paRT name
QTY.
RemaRkS
1@#$%+=
0189
GRIP, hANDLE
4
2@#$%+=
10133
NuT, NYLOC 3/8-16
4
3@#$%+=
12220
WAShER, LOCK 1/2 hIGh STRENGTh
12
4@%
26375
6 IN. hANDLE ExT, ENG END
2
4#+
26374
12 IN. hANDLE ExT, ENG END
2
4$=
26376
18 IN. hANDLE ExT, ENG END
2
5@#$%+=
16195
hANDLE, SCREED
4
6@#$%+=
16630
WAShER, FLAT 1/2 SAE hARDENED
24
7@#$%+=
1665
SCREW, hhC 3/8-16 x 2
4
8@#$%+=
2621
ZERK, GREASE ...................................................1 ........... INCLuDED WITh ITEM 18
9@#$%+=
1162 A
CAP, GREASE ZERK #2
1
11@#$%+= 3242
SCREW, hhC 1/2-13 x 1-3/4
12
13@#$%+= 968011
NuT, hEx FINISh 1/2-13
12
14@#$%+= 16154
MOuNT, END SECTION bEARING
1
15@#$%+= 13351
WAShER, FLAT 3/8 PLTD uSS hEAVY
8
16@#$%+= 1665
SCREW, hhC 3/8-16 x 2
2
18@#$%+= 16194
bEARING, PILLOW bLOCK
1
19@#$%+= 26250
SCREW, hhC 1/4-20 x 1-3/4
8
20@#$%+= 10024
NuT, NYLOC 1/4-20
8
21@#$
36646
TubE ASSY, 12.63"
2
22@#$
49048
SCREW, hhFS 1/4-20 x .75
8
25@#$
36591
MOuNT, hALF TubE
2
26@#$
26100
bOLT, 1.0-14 x 1.25 uNS-2A ThREAD
2
27@#$
3264
WAShER, FLAT SAE 1.00
2
28@#$
26099
ADAPTER, STAbILIZER END L/h
1
29@#$
26098
ADAPTER, STAbILIZER END R/h
1
30@
26389
6 IN. hANDLE ExT ASSY, ENG END ..................2 ........... INCLuDES ITEMS W/%
30#
26390
12 IN. hANDLE ExT ASSY, ENG END ................ 2 ........... INCLuDES ITEMS W/+
30$
26391
18 IN. hANDLE ExT ASSY, ENG END ................ 2 ........... INCLuDES ITEMS W/=
31
WShEExT6
SCREED, ENGINE, 6 IN. ExTENSION KIT ......... 1 ........... INCLuDES ITEMS W/@
31
WShEExT12 SCREED, ENGINE, 12 IN. ExTENSION KIT ....... 1 ........... INCLuDES ITEMS W/#
31
WShEExT18 SCREED, ENGINE, 18 IN. ExTENSION KIT ....... 1 ........... INCLuDES ITEMS W/$
