ESSICK EM-120SM — OPERATION AND PARTS MANUAL — REV. #5 (03/29/10) — PAGE 33
EM-120SM — WISCONSIN ENGINEASSY.
WISCONSIN ENGINE ASSY.
NO PART NO PART NAME QTY. REMARKS
1 EM937029 9.2 HP WISCONSIN ENGINE 1
2 EM940734 KILL SWITCH 1
3 EM203298 ENGINE KILL GROUND WIRE 1
4 EM203299 ENGINE KILL WIRE 1
5 0169 HHCS 3/8-16 x 3" 4
6 10136 FLAT WASHER 3/8" 8
7 EM100235 ENGINE SHIM .030 AR
EM100236 ENGINE SHIM .018 AR
EM100237 ENGINE SHIM .010 AR
8 EM203007 ENGINE PAD .187 AR
EM203016 ENGINE PAD .135 AR
EM203017 ENGINE PAD .060 AR
9 10133 LOCK NUT 3/8-16 4
10 EM912104 1" PIPE NIPPLE x 10" LONG 1
11 5081 1" 90 DEG. ELBOW 1
12 EM912097 1" PIPE NIPPLE x 5" LONG 1
13 EM010009 SQ KEY 1/4 x 1/4 x 1" 1
14 EM961045 SHSS 5/16-18 x 1/2" NYLOC 1
15 * EM925013 LEVER PIN 3
16 * EM925018 SHORT LINK PIN 3
17 * EM925016 LONG LINK PIN 3
18 * EM959012 LEVER 6
19 * EM934054 ROLLER 3
20 * 5117 COTTER PIN 9
21 * EM934053 CONNECTING LINK 6
22 * 9503 SLOTTED HHCS 1/4-20 x 1/2" 1
23 * EM934040 ADJUSTING LOCK 1
24 * EM934039 CLUTCH HOUSING 1
25 * EM918009 SPRING 3
26 * EM934041 SPLINED CENTER W/FACING 1
27 * EM934042 PRESSURE PLATE ASSY. 1
28 * EM934043 RELEASE SLEEVE 1
29 * EM934045 ADJUSTING RING 1
30 * EM963289 BOLT 2
31 * EM969009 LOCK NUT 2
32 * EM934004 RELEASING BEARING ASSY. 1
33 EM801570 PILOT BUSHING 1
EM934022 CLUTCH ASSY. ......................................................... 1 ........ INCL. ITEMS W/ *
