page 8 — SS233 SubmerSible pump • operaTion and parTS manual — rev. #2 (03/22/10)
speCifiCatiOns
Table 1. Specifications
model SS233
Type Submersible Pump
impeller Plastic
Suction & discharge Size 2.00 in. (50.8 mm)
maximum pumping Capacity
60 gallons/minute
(227 liters/minute)
discharge Height
above pumping level
5 ft (1.5 meters) 3,318 gallons/hr (12,560 liters/hr)
10 ft (3.0 meters) 2,808 gallons/hr (10,629 liters/hr)
15 ft (4.5 meters) 1,482 gallons/hr (8,358 liters/hr)
20 ft (6.0 meters) 1,482 gallons/hr (5,610 liters/hr)
30 ft (9.1 meters) 300 gallons/hr (1,136 liters/hr)
power 0.5 HP (0.37kw)
voltage phase 115V 1Ø
Starting amps 30.0
running amps 6.0
Thermal overlaod protection YES
rotation CCW
power Cable length 20 ft. (6.096 meters)
dimensions (dia x Height) 8.0 in. (20.3 cm.) x 14.5 in. (36.8 cm.)
dry Weight (Shipping) 16.5 lbs. (7.5 Kg.)
dry net Weight 15.5 lbs. (7.0 Kg.)
1. motor rotation — Upon start-up, the pump "kicks" in the opposite direction of motor rotation. The correct rotation is
counter-clockwise (CCW) as viewed from the impeller end of the pump.
NOTICE
Pumps with the "CSA" mark are tested to UL standard
UL778 and certified to CSA standard C22.2 N0. 108.
