QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 29
NO. PART NO. PART NAME QTY. REMARKS
1 1992100011 CASING 1
2 1992100020 CASING COVER 1
3 13910001600014 SUCTION COVER 1
4 1992100173 DRAIN COVER 1
5 19920002200014 DRAIN COVER KNOB 4
6 2368040031ASSY IMPELLER ASSY. ..................................................1............INCLUDES ITEMS W/ #
7 1992000133 VOLUTE CASING, 2-POST ...................................1............OLDER STYLE VOLUTE
WILL CROSS TO 3T4PKIT
7 2368000110 VOLUTE CASING, 4-POST ...................................1............NEW STYLE 4-POST
8 1992100742 SUCTION PLATE 1
9 1247100250 DRAIN COVER SET HANDLE 2
10 1992330410 SUCTION PLATE PACKING 1
11 1992250700 WEAR PLATE 1
12 0105090820 BOLT (CASING COVER), M8 x 20 4
13 07904330300014 NIPPLE, NPS3” X NPT3” 2
14 1378350350 CHECK VALVE 1
15 0105090825 BOLT(ENGINE), M8 X 25 4
16 43130006000014 CASING COVER SET PLATE 1
17@ 0483602250 O-RING (DRAIN COVER) 1
18 0489403400 O-RING (CASING), 4 X 340 MM 1
19 2367214010P002 BASE, SS400 1
20 0481310800 O-RING (NIPPLE) 2
21@# 0482200240 O-RING, IMPELLER, MECH SEAL .......................2............SEE NOTICE BELOW
22 23672140200014 ENGINE BASE,SS400 1
23 0631211159 FLOODING CAP, PF1 1/2” W/ O-RING 1
24 0631211159 DRAIN CAP, PF1 1/2” W/ O-RING 1
25@ 0803442930 MECHANICAL SEAL 1
26@ 0811885446 MECHANICAL SEAL SLEEVE, DIA. 30MM 1
27@ 0852834525 ADJUST LINER, 45 x 25.4 MM T0.3 1
27-1@ 0852854525 ADJUST LINER, 45 x25.4 MM T0.5 1
28 0105091025 BOLT(CASING COVER SET PLATE) M10 X 25 4
29 0131190823 CAP SCREW (VOLUTE CASING), M8 X 20 4
30 0141090825 SCREW (DRAIN COVER SET HANDLE),M8 X 25 4
31 0131191290 CAP SCREW (CASING), M12 X90 1
32 0131191235 CAP SCREW (CASING), M12 X 35 4
33 0105091040 BOLT (PUMP), M10 X 40 2
34 0459220120 SEAL WASHER(CASING), M12 1
35 0723302040 CUSHION RUBBER 40 X 20 MM M10 4
36# 0458220100 SEAL WASHER, IMPELLER 1
37# 0191190750 BOLT, IMPELLER 1
PUMP ASSEMBLY
NOTICE
Item 21, o-ring, is included in impeller kit, item 6. When
ordered as part of the kit, quantity of o-ring is one.
Replacement of impeller requires two o-rings, so it is
necessary to order one additional o-ring.
