QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 11
Table 1. Specifications (Pump)
Pump
Model QP3TZ
Type Trash Pump
Suction 3.0 in. (76 mm.)
Discharge Size 3.0 in. (76 mm.)
Maximum Pumping
Capacity
383 gallons/minute
(1,450 liters/minute)
Max. Solids Diameter 1.0 in. (25.4 mm)
Max. Head 90 ft. (27.0 m)
Max. Lift 25 ft. (7.62 m)
Max. Pressure 38.9 psi (268 kPa)
Dry Net Weight 163 lbs. (74 Kg.)
SPECIFICATIONS (PUMP)
Figure 1. QP3TZ Dimensions
23.6 IN.
(59.9 CM.)
19.0 IN.
(48.2 CM.)
26.9 IN.
(68.3 CM.)
