QP2E CENTRIFUGAL PUMP • OPERATION AND PARTS MANUAL — REV. #0 (02/12/09) — PAGE 45

ROBIN EX130D51111 ENGINE — CARBURETOR ASSY.

NO.

PART NO.

PART NAME

QTY.

REMARKS

A

2766230130

CARBURETOR ASSY .......................................1................INCLUDES ITEMS W/ #

1# 1066253808

THROTTLE

VALVE

1

2# 2096235108

SCREW

1

3# 2776252508

CHOKE

VALVE

1

5# 2466242008

PILOT

JET

1

8# 2776252008

CHOKE

LEVER

1

11#

2766253018

THROTTLE SHAFT A

1

12# 2276245108 BOLT

1

14# 2776250008 NEEDLE

1

15# 2776251508 PIN

1

16#

2776250608

FLOAT BODY ASSY

1

17# 2146245008 PACKING

1

18# 2146254008 CHAMBER

PACKING

1

19# 2266250608 FLOAT

1

20# 2766244008 MAIN

NOZZLE

1

22# 2776240418 MAIN

JET

1

24# 2266270118 CLIP

1

28# 2776236008 BOLT

1

40# 1066255608 SCREW

1

41# 2836235708 SPRING

1

44# 2076241008 AIR

JET

1

45#

1066241008

AIR JET (PILOT)

1

79# 2366254108 PACKING

1

144# 2776255308 NUT

1

300#

2796210310

COCK BODY- A

1

302# 2776211018 PACKING

1

303# 2776210018 CUP

1

325# 2776255208 O-RING

1

327# 1656237708 SCREW

2

224

2774380101

CHOKE LEVER CP

1

540

27732902J1

INSULATOR CP .................................................1................INCLUDES ITEMS W/ $

550$

27735903J3

GASKET 2 (INSULATOR)

1

560$

27735902J3

GASKET 1 (INSULATOR)

1
