MVH308DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (05/08/14)— PAGE 71
HATZ 1B30 ENGINE — CYLINDER HEAD ASSY., CONTINUED
NO. PART NO. PART NAME QTY. REMARKS
36-1 05096601 GASKET, CYLINDER HEAD 0.6 .......................1................SELECT 0-1
36 04248900 GASKET, CYLINDER HEAD 0.65 .....................1................SELECT 0-1
37-1 05096701 GASKET, CYLINDER HEAD 0.7 .......................1................SELECT 0-1
37 04249000 GASKET, CYLINDER HEAD 0.75 .....................1................SELECT 0-1
38 05096801 GASKET, CYLINDER HEAD 0.8 .......................1................SELECT 0-1
39 05096901 GASKET, CYLINDER HEAD 0.9 .......................1................SELECT 0-1
40 05097001 GASKET, CYLINDER HEAD 1.0 .......................1................SELECT 0-1
42 04229000 CENTER BUSH 2
43 04126100 PROTECTION HOSE 2
44 50396600 HEXAGON NUT M10 2
45 04243700 DISC 2
46 50563900 O-RING 2
47 01936500 CAP SCREW, CYL. HEAD COVER ASSY. .......1................INCLUDES ITEMS W/ @
48@ # CAP SCREW, CYL. HEAD COVER ...................1................NOT SOLD SEPARATELY
49@# 05278401 SEALING RING 2
50# 05321100 CONNECTING PIECE 1
51# 05321210 COVER, CYLINDER HEAD 1
52 01911201 COVER, CYLINDER HEAD ASSY. ...................1................INCLUDES ITEMS W/ #
