Multiquip MVH308DZ - Manual (Page 45)

MVH308DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (05/08/14)— PAGE 45
NO. PART NO. PART NAME QTY. REMARKS
52 467466760 STOPPER, COVER 1
53 009120424 SOCKET HEAD BOLT 3
54 617465130 COLLAR 3
55 030206150 WASHER, LOCK 3
56 022710607 NYLON NUT 3
57 467351820 CLEANER STAY 1
58 014208020 BOLT .................................................................4................REPLACES 01220820
59 030208200 WASHER, LOCK 4
60 040145008 WASHER, FLAT ................................................4................REPLACES 031108160
61 465459670 OIL DRAIN 1
62 50001600 JOINT A 1
81 467466780 EX. PIPE 1
82 506397-00 PIPE CLIP 1
83 040145008 WASHER, FLAT ................................................2................REPLACES 031108160
85 05165000 GUIDE BUSH 1
86 50484600 PRESSURE SPRING 1
87 01647300 CABLE CLAMP 2
88 50025000 HEX SCREW 1
89 020106050 NUT ...................................................................2................REPLACES 020306050
91 2067550101 CLAMP COMPL. 1
95 009120420 SOCKET HEAD BOLT 4
100 466218080 CLEANER, CYCLONE 1
101 467351890 CYCLONE STAY 1
102 466462850 GASKET, AIR INTAKE 2
103 467466840 JOINT, C-CLEANER 1
104 009110057 SOCKET HEAD BOLT 3
105 014208020 BOLT .................................................................2................REPLACES 001220820
106 030208200 WASHER, LOCK 2
107 040145008 WASHER, FLAT ................................................2................REPLACES 031108160
108 506010060 CLAMP TC-350 2
110 465348910 DUCT HOSE 1
111 467466850 INTAKE PIPE 1
112 467466860 GROMMET, CLEANER 1
116 955407970 WIRING, FIXED BASE 1
BASE AND ENGINE ASSY. CONTINUED
