MVH308DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (05/08/14)— PAGE 61
HATZ 1B30 ENGINE — CRANKCASE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
A 50223001 LOCTITE ACTIVATOR N, 500 ML 1
B 50223101 LOCTITE 574, 50 ML 1
D 70018918 LOCTITE 243, 50 ML 1
E 50223400 LOCTITE 648 1
H 70018944 TEROSON TEROSTAT 63 1
1 01582720 CRANKCASE ASSY. .........................................1................INCLUDES ITEMS W/ $
2$ CRANKCASE .....................................................1................NOT SOLD SEPARATELY
3$ PLUG .................................................................1................NOT SOLD SEPARATELY
5$ 40002600 BLIND RIVET 1
6$ 01333111 COVER SHEET 1
7$ 50502801 CYLINDER PIN 1
8$ 50440300 O-RING 1
9$ 50249102 Z CYLINDER PIN 1
10$ 50062400 JOINT A 1
11$ 50469101 OIL PRESSURE SWITCH 1
12$ PLUG .................................................................1................NOT SOLD SEPARATELY
14 50449800 OIL SEAL 1
15 04198700 GRUB SCREW CARB/EPA 1
16 01316000 DIPSTICK ASSY. ..............................................1................INCLUDES ITEMS W/@
17@ 04125000 SEALING RING, DIPSTICK 1
18@ DIPSTICK ..........................................................1................NOT SOLD SEPARATELY
19 50208500 WASHER, LOCK 1
20 04121900 ALLEN SCREW 1
21 04099302 ENGINE BRACKET 1
22$ 04105710 TUBE F. OIL FILTER 1
23 01542704 OIL SUCTION FILTER ASSY. ............................1................INCLUDES ITEMS W/ #
24 50373100 DRAIN PLG. MAGNT. M22 1
25 50001600 GASKET 1
26$ 05036900 HOSE CLIP 1
27$ 04163000 T-PIECE 1
29 50449700 GROOVE BALLBEARING 1
30 04094400 PLATE 1
31 50564300 COUNTERSUNK SCREW 1
32 01555800 COVER 1
33 03568701 OIL SUPPLEMENT PLUG 1
35# OIL SUCTION FILTER .......................................1................NOT SOLD SEPARATELY
36# 50475901 O-RING 1
37# 05148200 PLATE SPRING 1
38# 50170700 ALLEN SCREW 1
42# 04042000 WASHER 1
