MVH408DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (04/24/14)— PAGE 95
HATZ 1B50 ENGINE — AIR FILTER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 01637410 AIR FILTER HOUSING ASSY. ...........................1................INCLUDES ITEMS W/ $
2$ HOUSING, AIR FILTER .....................................1................NOT SOLD SEPARATELY
3$ 05167700 SEALING STRIP 665MM 1
4$ 05166200 RUBBER SHELL 32MM 1
5 50095100 WASHER, LOCK A8 3
6 50171500 ALLEN SCREW M8X25 3
7$ 50484100 AIR FILTER ELEMENT 1
8 50454300 KNURLED NUT M6 1
9 01822001 COVER, AIR FILTER ASSY. .............................1................INCLUDES ITEMS W/ %
10% 05158000 SEALING STRIP 1
11% COVER, AIR FILTER .........................................1................NOT SOLD SEPARATELY
12 50435800 RUBBER SLEEVE 1
13 50452200 WING NUT M6 1
16 05149900 GASKET AIR FILTER 2
17 05149801 INSULATING FLANGE 1
18 04215200 CLOSING COVER 1
37 04215300 CLOSING COVER 1
38 05309300 BREATHER TUBE 1
39 05098100 PLUG 1
41 50591500 SHIM 9X15X1.0 1
42 50591600 TUBE RIVET A8X0.5X12 1
