MVH408DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (04/24/14)— PAGE 11
SPECIFICATIONS
Table 1. MVH408DZ Specifications
Centrifugal Force 12,365 lbf (55 kN)
Vibration Frequency 4,400 vpm (73 Hz)
Maximum Traveling Speed 79 ft/min (24 m/min)
Plate Size (W x L) 19.68 x 35.43 in (500 x 900 mm)
Plate Size (W x L) with extension plates 25.59 x 35.43 in (650 x 900 mm)
Max. Forward Speed 82 ft./min (25 m/min)
Operating Weight 899.48 lbs. (408 kg.)
Operating Weight with extension plates 932.55 lbs. (423 kg.)
Table 2. Engine Specifications
Engine Make HATZ
Engine Model 1B50T-9-166
Engine Type Air-cooled, 4 Cycle Diesel Engine
Cylinder Bore X Stroke 3.66 in. x 2.99 in. (93 mm x 76 mm)
Displacement 31.55 cu-in (517 cc)
Maximum Ouput 9 BHP (6.7 kW) @ 2500 RPM
Fuel Tank Capacity Approx. 1.4 U.S. gallons (5.3 liters)
Fuel Type Diesel
Oil Capacity 1.58 qts (1.5 liters)
Starting Method Recoil/Electric Start
Dry Net Weight 123.46 lbs (56 Kg.)
