MVH408DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (04/24/14)— PAGE 87
NO. PART NO. PART NAME QTY. REMARKS
F 50223800 TECHNICAL ADHESIVE 8058 1
1 01831301 BLOWER DUCTING ASSY. ..............................1................INCLUDES ITEMS W/ $
2$ HOUSING, BLOWER DUCT ..............................1................NOT SOLD SEPARATELY
3$ 01331300 SUPPORT 2
4$ 50453300 RUBBER SLEEVE 1
5$ 05401600 SEALING STRIP 715MM 1
6$ 05401500 SEALING STRIP 555MM 1
7$ 05401400 SEALING STRIP 57MM 1
8 020106050 HEXAGON NUT M6 ..........................................2................REPLACES 50144400
9 50170900 WASHER, LOCK 6 2
10 020106050 HEXAGON NUT M6 ..........................................7................REPLACES 50144400
11 50170900 WASHER, LOCK 6 8
12 50120000 DISC A 6.4 3
14 01347600 PROTECTION SHIELD ......................................1................INCLUDES ITEMS W/ %
15% SHIELD, PROTECTION .....................................1................NOT SOLD SEPARATELY
16% 01378300 SPACER BUSHING 4
17% 03575500 RUBBER SEAL RING 4
20% 04215200 CLOSING COVER 1
21 50458100 STUD M6X45 2
22 50114300 DISC 6.4 2
23 50464401 STUD M6FOX35 2
24 04042000 WASHER 6.5X22.5X1 7
26 05188600 SPACER BUSH 7X12X7 2
27 50328300 HEXAGON NUT VM6 2
28 04139000 SPACER TUBE 6.5X12X18 4
29 04098400 SPACER TUBE 7X12X16.3 2
30 05184000 HEXAGON NUT M6X17 1
31 50026400 HEXAGON SCREW M6X35 1
32 01669400 SUPPORT 1
33 020106050 HEXAGON NUT M6 ..........................................1................REPLACES 50144400
34 50170900 WASHER, LOCK 6 2
35 50170700 ALLEN SCREW M6X16 1
36 01683300 SUPPORT 1
37% 04099500 SEALING RING 1
38 05140900 WASHER 1
39$ 50392610 RUBBER BUSHING ..........................................1................SELECT 0-4
43 05314300 STICKER 1
44$ 05401300 PROTECTION 58MM 1
HATZ 1B50 ENGINE — AIR DUCTING B ASSY.
