R2000H RIDE-ON STATIC ROLLER — OPERATION AND PARTS MANUAL — REV. #6 (11/29/10) — PAGE 23
R2000H — INITIAL START-UP
1. Sit down in the operator's seat.
2. Before starting engine, make sure the immediate area is free
of obstructions and debris that may lay in the roller's path.
3. Make sure that the roller's transmission control lever (Figure
10) is placed in the neutral position .
Starting the Engine
1. Place the engine fuel valve lever (Figure 11) to the "ON"
position.
Figure 11. Engine Fuel Valve Lever
2 Rotate the throttle lever (Figure 12) halfway between fast
and slow for starting. The engine governor speed is factory
set to ensure optimum operating speeds.
Figure 12. Throttle Lever
CAUTION:
DO NOT attempt to operate the roller until the
Safety, General Information and Inspection
sections have been read and understood.
Figure 13. Choke Lever
3. Place the Choke Lever (Figure 13 in the " CLOSED "
position.
The CLOSED position of the
choke lever enriches the fuel
mixture for starting a COLD engine.
The OPEN position provides the
correct fuel mixture for normal
operation after starting, and for
restarting a warm engine.
NOTE
Figure 10. Transmission Control Lever
NOTE
NEVER operate the roller with the
access cover open. Keeping the
cover closed will prevent dirt and
debris from entering into the
transmission and drivetrain
assemblies. ALWAYS keep the
access cover closed for normal
operation.
