28 P54
K/K2B/K4B
Operation :
Adjusting lever VS3 : Setting the tilt of the backrest by turning the adjusting
knob.
Adjusting lever VS4 : This lever is used to move the entire driver's seat forwards
or back.
______________________________________________________________________________________
7.0 Loading and transport :
• The roller can be loaded by being driven up a suitable loading ramp.
Note :
• Only loading ramps with sufficient loading capacity and static stability must be used which
exclude any possibility of personal injury.
• To lash the roller, always use shackles which are fastened to the transportation eye bolts
"TÖ" (at the front and back of the roller (Fig. 22/23).
• The roller must be lashed in such a way that it is secured against tipping over, slipping or
rolling away, and that the roller does not pose a danger to persons.
• Do not tread or stand under suspended loads.
Fig. 22 Fig. 23
TÖ
TЦ
