MK Diamond MK-3000 Series - Manual (Page 22)

22
MK-3000 SERIES OPERATION
WARNING
Observe the rotation arrow on blade and DO NOT exceed maximum RPM stamped on the blade. To
set proper RPM, consult the Blade Guards and Blade Sizes Table on page 15.
6. Tighten the arbor bolt (Figure 12).
7. Install the blade guard in place. Make sure that the guard locks in place and connect the hose
(Figure 13).
NOTICE
To meet ANSI safety standards, larger diameter blade collars are required for large diameter blades.
Information is available upon request.
NOTICE
We recommend the use of MK Diamond blades with this saw.
BLADE MOUNTING INSTRUCTIONS CONTINUED
Fig. 12 Tighten Arbor Bolt Fig. 13 Install Blade Guard
