MK-377 SAW INSTALLATION
(E)
Install Diamond Blade onto
Blade Shaft
(D)
Place the Blade Wrench on the
Blade Retaining Nut and remove
the Blade Retaining Nut and
Outer Flange
(F)
Verify the Directional Arrow of
the Blade faces outward and
matches the Directional Arrow of
the Blade Guard
(H)
Close the Blade Guard and
tighten the Blade Guard
Retaining Knob
(G)
Install the Outer Flange and
Retaining Nut; install the Shaft
Wrench and Blade Wrench as
shown in Steps C and D and
tighten the Retaining Nut
(I)
Tighten the Blade Guard
Retaining Wingnut
