Mayline Dual Adder - Manual

When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS:
Item # QTY. DESCRIPTION PART #
1 1 LEG, ADDER A8046**
2 1 BEAM ASSEMBLY Call~~**
3 2 TROUGH SIDE Call~~**
4 1 PAN Call~~**
ASSEMBLY INSTRUCTIONS
TRANSACTION DUAL ADDER
Item # QTY. DESCRIPTION PART #
5 2 WORK SURFACE Call~~**
6 0/4/6 ACCESS PANEL Call~~**
7 2 INNER LEG PANEL B8219**
8 2 ANGLE, TOP JOINING B8224**
** Denotes Color Code
~~Denotes Size
HARDWARE BAG (PART No. A8100)
* for individual item, order that part number
** HARDWARE BAG LOCATED IN BEAM ASSEMBLY **
Item # QTY DESCRIPTION PART #
E1 2 TUBE INSERT, 5/16-18 T139*
E2 2 GLIDE Q608*
E3 13 SCREWS #10-32 x 1/2" X204*
E4 4 WASHER, EXT STAR #10 W38*
E5 25 SCREW #10 x 3/4 X11*
E6 6 SCREW #10 x 1 X12*
E7 3 PLUG, SQUARE HOLE F782*
E8 2 SLAM LATCH Q643*
E9 2 BUSHING F764*
E10 8 PINE TREE CLIP F483*
E11 4 PINE TREE CLIP F529*
