Mayline Dual Starter - Manual

When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS:
Item # QTY. DESCRIPTION PART #
1 2 LEG A8043**
2 1 BEAM ASSEMBLY Call~~**
3 2 TROUGH SIDE Call~~**
4 1 PAN Call~~**
HARDWARE BAG (PART No. A8076)
* for individual item, order that part number
Item # QTY DESCRIPTION PART #
E1 4 TUBE INSERT, 5/16-18 T139*
E2 4 GLIDE Q608*
E3 13 SCREWS #10-32 x 1/2" X204*
E4 4 WASHER, EXT STAR #10 W38*
E5 28 SCREW #10 x 3/4 X11*
E6 3 PLUG, SQUARE HOLE F782*
E7 2 SLAM LATCH Q643*
E8 2 BUSHING F764*
E9 8 RATCHET FASTENER F483*
E10 4 PINE TREE CLIP F529*
ASSEMBLY INSTRUCTIONS
TRANSACTION DUAL STARTER
Item # QTY. DESCRIPTION PART #
5 2 WORK SURFACE Call~~**
6 0/4/6 ACCESS PANEL Call~~**
7 2 OUTER LEG PANEL TADEP**
8 2 INNER LEG PANEL B8219**
** Denotes Color Code
~~Denotes Size
