Mayline Forester Wood 4-Post Table - Manual

ASSEMBLY INSTRUCTIONS for
FORESTER WOOD FOUR-POST
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
COMPONENTS:
REF. # QTY. DESCRIPTION PART No.
1 1 TOP CALL~~
2 2 TILT ROD ASSEMBLY A315
3 1 L.H. TABLE END ASSEMBLY CALL~~**
4 1 R.H. TABLE END ASSEMBLY CALL~~**
5 1 FRONT RAIL ASSEMBLY CALL~~**
6 1 PENCIL TROUGH F249P
7 1 UPPER BACK RAIL CALL~~**
8 1 LOWER BACK RAIL CALL~~**
9 1 WELL BOTTOM CALL~~**
HARDWARE BAG (PART No. A7729)
*for individual item, order that part number
REF. # QTY DESCRIPTION PART No.
E1 2 TILT ROD GUIDE B160*
E2 2 UPPER HINGE B194*
E3 2 RUBBER BUMPER D38*
E4 2 KNOB K13*
E5 6 SQUARE NUT T12*
E6 2 WASHER W8*
CATALOG No:
7602 7603
7604 7606
** Denotes Color Code
~~Denotes Size
REF. # QTY DESCRIPTION PART No.
E7 2 5/16-18 x 1 1/4 SCREW X102*
E8 2 #10 x 1 SCREW X12*
E9 6 1/4-20 x 4 SCREW X210*
E10 12 #10 x 5/8 SCREW X5108*
E11 2 RUBBER BUMPER D10*
CATALOG No:
7603LT
(1)
