INSTALLING YOUR ICE MACHINE OR FREEZER
Select Location
The proper location will ensure peak performance of your ap-
pliance. We recommend a location where the unit will be out
of direct sunlight and away from heat sources. To assure your
product performs to specifications the recommended installation
location temperature range is from 65 to 90°F (18 to 32°C).
Cabinet Clearance
Ventilation is required from the bottom front section of the unit.
Keep this area open and clear of any obstructions. Adjacent
cabinets and counter top can be installed around the unit as long
as the grille and door access remain unobstructed.
Front leveling legs
Front Grille, keep
this area open.
Figure 1
Leveling Legs
Adjustable legs at the front and rear corners of the unit should
be set so the unit is firmly positioned on the floor and level from
side to side and front to back. The overall height of your Marvel
refrigerator, depending on the model, may be adjusted from 24-
1/8” (61.3cm) or 33-3/4” (85.7cm) with the leveling legs turned
in, and up to 25-1/8” (63.8cm) or 34-3/4” (88.3cm) with the
leveling legs extended.
To adjust the leveling legs, place the refrigerator on a solid sur-
face and protect the floor beneath the legs to avoid scratching
the floor. With the assistance of another person, lean the refrig-
erator back enough to access the front leveling legs and remove
the weight. Raise or lower the legs to the required dimension
by turning the legs. Repeat this process for the rear by tilting
the refrigerator forward using caution to prevent the door from
opening. On a level surface check the refrigerator for levelness
and adjust accordingly.
The front grille (toe kick) screws may be loosened and adjusted
to the desired height. When adjustment is complete tighten the
two toe kick screws. (See Figure 2).
Figure 2
Toe kick (Front Grille)
Toe kick screw
4
Front Grille
Do not obstruct the front grill. The openings within the front
grill allow air to flow through the condenser heat exchanger.
Restrictions to this air flow will result in increased energy usage
and loss of cooling capacity. For this reason it is important this
area to not be obstructed and the grill openings kept clean. AGA
MARVEL does not recommend the use of custom made grills as
air flow may be restricted because of inadequate openings. (See
Figure 1).
