Page 9: 1a-7

1A
OPERATIONS
1A-7
36
72"
1828mm
46
78"
1981mm
36
38"
965mm
46
48"
1219mm
36
36"
914mm
46
39"
991mm
1.6 Dimensions
TROWEL
36"
36" EDGER
46” 9HP
46" 11HP
Length - in. (mm)
72 (1828)
80 (2032
78 (1981)
78 (1981)
Width - in. (mm)
38 (965)
36.5 (927)
48 (1219)
48 (1219)
Operating Weight - lbs (kg)
230 (104)
226 (102)
238 (108)
238 (108)
Troweling Width - in. (mm)
36 (914)
36.5 (927)
46 (1168)
46 (1168)
Rotor Speed - RPM
118
118
118
118
Pitch Range - Degrees
0 - 20
0 - 20
0 - 20
0 - 20
Gear Box
Standard
Standard
Standard
Standard
Safety Switch - handle mount
Yes
Yes
Yes
Yes
Gear Box Lub. - 25 oz.
Special Formula
Part# M048299
Special Formula
Part# M048299
Special Formula
Part# M048299
Special Formula
Part# M048299
CAUTION
!
DO NOT mix different types of gear oil.
DO NOT overfill the gearbox with gear oil.
Damage to the gearbox may occur if gear oils
aremixed, or if the gearbox is overfilled.
