Fig. 7, Fig. 8 – Lightforce Genesis HID UPGRADE KIT User Manual
Page 2
User Instructions
SAFETY NOTES
DO NOT CUT ANY PART OF THE BALLAST OR BULB CABLES
DO NOT USE ADDITIONAL CABLES BETWEEN THE BALLAST AND THE BULB
ALWAYS DISCONNECT POWER BEFORE DISASSEMBLY OF LIGHT
ALWAYS WEAR SAFETY GLASSES WHEN HANDLING ANY BULB
DO NOT HANDLE THE GLASS SECTION OF BULB
Handle the base of bulb only, if glass gets dirty then clean with Isopropyl Alcohol or Methylated Spirits.
READ ALL INSTRUCTIONS BEFORE COMMENCING INSTALLATION
Box Contents
Tools Required
INSTRUCTION DATA
PRODUCT: XGT HID UPGRADE
VER:
1.0
DATE:
APRIL 2013
50w HID Ballast x2
Globe assembly retainer x2
50w HB3 Bulb x2
Ballast retaining bracket x2
PK Screws (PH1) x2
Red dress ring x2
1
6
FIG. 7
Connect HID globe/holder to shroud
FIG. 8
0
5
25
75
95
100
