Lightforce 35W HID GLOBE REPLACEMENT User Manual
Handheld sl-hid user instructions, Instruction data, Specifications

1. DO NOT leave light connected to a power source when not in use.
2. DO NOT place light face down on ANY surface. If the light is switched on the intense heat generated may ignite the
surface and cause a melt down of the lamp body.
3. Ensure all electrical connectors are secure - loose connections will generate excessive heat, damage wiring and cause
electrical failure.
4. The outer lens should be washed clean with copious amounts of water and a clean sponge. Wiping it with a dry rag will
scratch the lens, especially if the surface is dusty. NEVER clean the light with cleaning fluid or solvent.
5. DO NOT attempt to clean the inside of the light or touch the inside lens and reflector.
6. FOCUSING MECHANISM: The patented focus mechanism allows precise adjustment of the beam to various
concentration patterns as desired. Simply rotate the reflector and select the desired SPOT.
7. Ensure during use reflector surface is not wound too far forward past the globe holder or melting of the housing can
occur and will not be covered under warranty.
8. DO NOT disassemble the light due to high internal voltage!
9. LIGHTFORCE AUSTRALIA PTY LTD shall not be liable for damage, malfunction, failure resulting from accident,
misapplication, misuse, unauthorised repair, neglect, modification, unauthorised or non standard replacement
parts, accessories, globes, batteries or voltage or the operation of the product beyond its technical and environmental
specifications. The purchaser acknowledges that local laws may prohibit the use of some of the product on motor
vehicles travelling on public roads and agrees that it is their responsibility to ascertain the effect of local laws.
SPECIFICATIONS
Weight SL170HID 870 grams, SL2406HID 1.2 kgs (includes coil cord)
Electrical Current consumption: 4 amp and 12v
Recommended Operating Temperature (ambient)
-40°C > +40°C Maximum, -40°F > +104°F Maximum
Replacement Bulb GL25 35W 5000°K Super White RM/RMDL
Lumen Output 35 watt 3200 lumens
Run time Operating duration greater than 3 hours from a Lightforce
9A/H battery pack
CHANGING THE BULB
HID bulbs are inherently reliable in the field. Because there is no filament in the bulb, premature failure is unusual however ,
over time the bulb output will diminish or if subject to extreme impact then follow these instructions to change the HID bulb.
i
Warning, the HID bulb operates at a high internal pressure. Use safety glasses and do not operate light without have the
reflector and lens assembly in place.
i
Hint, do not touch the surface of the bulb, handle with gloves.
To change the bulb, it is necessary to access the electrical connections that are built into the base of the handle.
i
Warning, high voltages are present in the base. Always ensure the light is disconnected from the power before opening the
case.
Handheld SL-HID USER INSTRUCTIONS
LIGHTFORCE AUSTRALIA PTY LTD • 28 Orsmond Street, Hindmarsh SA 5007 Australia • www.lightforce.com | email: [email protected]
Australia: Tel: 08 8440 0888 | Fax: 08 8346 0504 • Int’l: Tel: +618 8440 0888 | Fax: +618 8346 0504
All logos and images are subject to relevant trademark and copyright protection LIGHTFORCE Pty Ltd | © Jan 2012 • Data and specifications contained maybe subject to change without notice.
LIGHTFORCE Australia Pty Ltd shall not be liable for damage, malfunction, failure resulting from accident, misuse, misapplication, unauthorised repair, neglect, modification, unauthorised or non standard replacement parts,
accessories, bulbs, batteries or voltage or operation of the product beyond its technical and or environmental specification.
Lightforce Custom Built is a new division within Lightforce Australia offering a custom design and fabrication service, specialising in lighting solutions for customers with unique individial needs. Should you have any special requirement outside
of our standard lighting range, feel free to contact us to discuss your requirements.
INSTRUCTION DATA
PRODUCT: Handheld HID
VER: 1.0
DATE: APRIL 2012
